As a premier manufacturer of heavy-duty material handling equipment, we introduce our highly capable CE and EPA-certified diesel forklift series. Engineered for rigorous warehouse and all-terrain operations, this lifting truck seamlessly integrates raw power with precision control to elevate your facility's productivity.
Loading capacity ranging comprehensively from 1500 kg to 6000 kg.
Equipped with advanced side shifters and fork positioners for pinpoint accuracy.
Direct from the supplier with expedited global shipping and robust packaging.
Customizable configurations and attachments to meet diverse operational demands.
Step into the operator's cabin of this formidable diesel forklift, and immediately feel the solid, vibration-dampened steel beneath your feet. The satisfying, deep hum of the high-torque engine resonates with sheer mechanical capability, promising relentless performance across the most demanding shifts. When you grip the mechanical joystick, the tactile feedback is instant and precise, allowing you to maneuver heavy, irregularly shaped pallets with the delicate touch of a master craftsman. The visual presence of the machine is striking; its electrophoretic spray paint gleams with a smooth, flawless finish that feels cool, unyielding, and completely impervious to rust when you run your hand along the chassis.
As the mast elevates, the hydraulic system operates with a smooth, powerful hiss, effortlessly lifting multi-ton loads without a single hint of structural strain or mechanical hesitation. Every component, from the thick engineering rubber tires gripping the slick concrete floor to the high-brightness LED lights cutting sharply through dim warehouse aisles, is meticulously assembled to transform your daily material handling challenges into a streamlined operation. The scent of industrial-grade hydraulic fluid and fresh, baked-on enamel serves as a testament to its brand-new, factory-tested pedigree. This isn't just a lifting truck; it is a heavy-duty asset engineered from the ground up to maximize your operational throughput, minimize downtime, and fiercely safeguard your bottom line in any harsh environment.
| Model | Unit | MY-20 | MY-30 | ||||
| Rated lifting load | kg | 1500 | 2000 | 2500 | 3000 | ||
| Load center distance | mm | 500 | 500 | ||||
| Free lifting height | mm | 100 | 150 | 160 | |||
| overall length (With fork/Without fork ) | mm | 3180/2260 | 3422/2502 | 3646/2576 | 3752/2682 | ||
| Width | mm | 1090 | 1170 | 1225 | |||
| Overhead guard height | mm | 2050 | 2070 | 2090 | |||
| Wheelbase | mm | 1400 | 1600 | 1700 | |||
| Minimum ground clearance | mm | 110 | 135 | ||||
| Mast tilt angle(front/rear) | % | 6°/12° | 6°/12° | ||||
| Tire no.(before) | 6.5-10-10PR | 7.00x12-12PR | 28x9-15-14PR | ||||
| Tire no.(after) | 5.00-8-10PR | 6.00x9-10PR | 6.5-10-10PR | ||||
| Minimum turning radius(outer side) | mm | 1950 | 2170 | 2240 | 2400 | ||
| Minimum right angle aisle width | mm | 3630 | 3900 | 3970 | 4260 | ||
| Fork size | mm | 920x100x35 | 1070X100X45 | 1070X125X45 | |||
| maximum working speed(Full-load/No-load ) | km/h | 14/15 | 17/19 | 18/19 | |||
| maximum lifting speed(Full-load/No-load ) | mm/s | 500/480 | 530/550 | 440/480 | |||
| maximum gradeability(Full-load/No-load) | % | 20/21 | 15/20 | ||||
| Forklift weight | kg | 2900 | 3320 | 3680 | 4250 | ||
| Engine model | Quanchai/B02-082 | Quanchai 4C2-50V32/Quanchai 4C2-50C41 | Quanchai 4C2-50V32/Quanchai 4C2-50C41 | ||||
| Model | Unit | MY-40 | MY-50 | MY-60 | MY-80 |
| Rated lifting load | kg | 4000 | 5000 | 6000 | 6000 |
| Load center distance | mm | 500 | 500 | 600 | 600 |
| Free lifting height | mm | 150 | 160 | 210 | 200 |
| overall length (With fork/Without fork ) | mm | 4000/2930 | 4190/3120 | 4720/3590 | 5175/3955 |
| Width | mm | 1290 | 1480 | 1970 | 2245 |
| Overhead guard height | mm | 2180 | 2240 | 2500 | 2570 |
| Wheelbase | mm | 1900 | 2000 | 2250 | 2800 |
| Minimum ground clearance | mm | 140 | 175 | 230 | 250 |
| Mast tilt angle(front/rear) | % | 6°/12° | 6°/12° | 6°/12° | 10°/12° |
| Tire no.(before) | 250-15-16PR | 300-15-20PR | 8.25-15-14PR | 9.00-20NHS | |
| Tire no.(after) | 7.00-12-12PR | 7.00-12-12PR | 8.25-15-14PR | 9.00-20NHS | |
| Minimum turning radius(outer side) | mm | 2710 | 2900 | 4120 | 3755 |
| Minimum right angle aisle width | mm | 4750 | 4960 | 5290 | 5755 |
| Fork size | mm | 1070x150x50 | 1070x150x55 | 1220x150x60 | 1520x170x70 |
| maximum working speed(Full-load/No-load ) | km/h | 19/19 | 18/19 | 23/29 | 20/26 |
| maximum lifting speed(Full-load/No-load ) | mm/s | 340/380 | 400/380 | 500/530 | 330/350 |
| maximum gradeability(Full-load/No-load) | % | 15/20 | 15/20 | 15/20 | 15/20 |
| Forklift weight | kg | 4950 | 6700 | 8900 | 11800 |
| Engine model | Quanchai 4C4-50V31 | Quanchai 4C6-85U32 | Quanchai 4J1-115C32 | Quanchai 4J1-115C32 |
At the core of our lifting trucks lies a powertrain designed for relentless performance and strict environmental compliance. The integration of the renowned Quanchai engine series ensures that your fleet possesses the torque necessary for heavy, continuous lifting without compromising on fuel efficiency or ecological responsibility.
High-Torque Output: Delivers consistent, stable power even when handling maximum rated loads of up to 6000 kg, ensuring no loss of momentum during critical lifts.
Global Compliance: Fully CE and EPA certified, ensuring your equipment meets the most stringent environmental regulations and emission standards required in advanced global markets.
Thermal Management: Advanced cooling systems prevent engine overheating during continuous, high-intensity operations, safeguarding your investment and preventing unexpected downtime.
Fuel Efficiency: Optimized combustion chambers maximize energy extraction from every drop of diesel, significantly lowering your daily operational expenditures.
The structural integrity of the lifting mechanism is paramount when handling valuable or hazardous materials. Our thickened mast system is forged from premium-grade steel, engineered to resist torsion and bending under extreme stress, providing absolute peace of mind during your most critical lifting tasks.
Heavy-Duty Steel Construction: The thickened mast profiles offer exceptional bearing capacity, ensuring zero structural deformation even at maximum load capacities.
Smooth Ascent and Descent: Precision-machined hydraulic cylinders guarantee a judder-free lifting experience, protecting fragile goods from impact damage during vertical transit.
Optimized Free Lifting Height: Ranging from 100mm to 210mm, allowing for seamless operation inside shipping containers, trailers, or areas with restricted overhead clearance.
Dynamic Tilt Angles: With a forward/backward tilt of up to 10°/12°, operators can secure loads swiftly and safely, preventing load shifting before transit begins.
Modern logistics demand adaptability. This forklift is designed as a versatile platform, ready to be customized with a variety of specialized attachments to suit the unique material handling requirements of your specific industry sector, transforming a single machine into a multi-purpose logistical tool.
Integrated Side Shifter: Allows lateral movement of the carriage, enabling precise pallet placement without the need to reverse and reposition the entire truck.
Hydraulic Fork Positioner: Operators can adjust the distance between forks directly from the cabin, accommodating different pallet sizes instantly and safely.
Expandable Architecture: Seamlessly compatible with paper roll clamps, bale clamps, and rotators to handle non-standard industrial materials with ease.
Quick-Change System: Engineered for rapid attachment swapping, minimizing operational downtime when transitioning between different types of cargo.
Operator well-being is directly correlated with facility productivity and safety. We have meticulously designed the cabin environment to minimize physical strain and maximize control, creating a workspace where operators can perform at their peak throughout their entire shift without experiencing debilitating fatigue.
Hydraulic Power Steering: Effortless maneuverability even in the tightest warehouse aisles, significantly reducing upper body strain and improving steering response.
Reinforced Overhead Guard: Constructed with heavy-duty steel to provide maximum protection against falling objects, ensuring operator safety in high-stacking environments.
Responsive Braking System: Delivers immediate, predictable stopping power even when fully loaded on a downward slope, preventing collisions and product damage.
Vibration Dampening: Specially engineered engine mounts and cabin suspension absorb operational shocks, providing a smooth and comfortable ride over uneven surfaces.
Industrial equipment must withstand harsh environments, from high humidity to chemical exposure. We employ advanced surface treatment technologies to ensure your forklift maintains its structural integrity and professional appearance year after year, protecting your capital investment.
Electrophoretic Spray Paint: This advanced coating process ensures uniform paint distribution, penetrating every crevice for ultimate rust prevention.
Smooth, Tactile Finish: The high-quality paint surface not only looks premium but repels dust and grime, making daily maintenance and cleaning effortless.
Corrosion Resistance: Specially formulated to withstand exposure to salt, moisture, and industrial chemicals, drastically extending the machine's lifespan.
UV Protection: The vibrant color finish resists fading and chalking even after prolonged exposure to direct sunlight in outdoor material yards.
Elevating your material handling capabilities requires equipment that goes beyond basic functionality. Our diesel forklift series is meticulously engineered to deliver a synergistic blend of power, precision, and longevity. Every component is selected to ensure that your operations run smoothly, safely, and with maximum cost-efficiency, allowing your team to focus on productivity rather than equipment limitations.
Precision Load Handling: Integrated fork positioners and side shifters eliminate the need for manual adjustments, allowing operators to align loads instantly and securely without leaving the cabin.
Ergonomic Command Center: The hydraulic power steering wheel and intuitive mechanical joysticks reduce operator fatigue, translating to higher focus and fewer errors during demanding, long-hour shifts.
Unobstructed Visibility: The wide-view mast configuration provides operators with a clear line of sight to the fork tips and surrounding environment, drastically reducing the risk of workplace accidents.
All-Weather Illumination: High-intensity LED lighting cuts through dimly lit warehouse aisles and outdoor fog, ensuring safe operation regardless of ambient light conditions.
Selecting the right equipment supplier is a critical strategic decision for your procurement team. We stand apart by combining decades of manufacturing expertise with a relentless commitment to quality control, ensuring that every machine leaving our facility is a testament to engineering excellence and reliability.
Direct Manufacturer Advantage: By eliminating intermediaries, we offer highly competitive procurement structures without ever compromising on component quality.
Stringent Quality Control: Every forklift undergoes rigorous load testing, hydraulic stress analysis, and emission checks before it is cleared for global shipping.
Flexible Financial Solutions: We accommodate standard 30% advance payments and accept L/C at sight, aligning smoothly with your organization's financial workflows.
Continuous Innovation: Our R&D team constantly refines our machinery based on real-world feedback, ensuring you always receive state-of-the-art equipment.
Dedicated Account Management: From initial consultation to post-delivery support, you receive personalized service tailored to your specific industry needs.
Q1: How does the electrophoretic paint process enhance the lifespan of the forklift?
A: Electrophoretic deposition ensures a highly uniform, dense coating that reaches deep into the metal's micro-cavities. This creates an impermeable barrier against moisture and industrial chemicals, preventing rust and structural degradation far better than traditional spray painting methods, thereby extending the operational life of the chassis and mast.
Q2: Can the hydraulic system handle continuous, high-cycle operations without overheating?
A: Yes. The hydraulic architecture is engineered with high-capacity fluid reservoirs and integrated thermal dissipation mechanics. This ensures the hydraulic oil maintains optimal viscosity, providing smooth and responsive lifting power even during continuous, multi-shift operations in demanding environments.
Q3: What specific advantages do the fork positioner and side shifter provide for warehouse efficiency?
A: These attachments drastically reduce the need for the operator to manually adjust the forks or physically reposition the entire truck to align with a pallet. This micro-adjustment capability saves crucial seconds on every single lift, significantly increasing overall pallets-per-hour throughput and reducing operator fatigue.
Q4: How does the Quanchai engine perform under maximum load capacities on inclines?
A: The Quanchai diesel engine is specifically calibrated for high low-end torque. When navigating up to a 20% gradient with a full load, the engine maintains consistent RPMs, preventing stalling and ensuring a smooth, controlled ascent without excessive fuel consumption or strain on the transmission.
Q5: What is the protocol for securing replacement parts to minimize operational downtime?
A: We maintain a comprehensive inventory of critical wear parts. Upon remote video diagnosis by our engineering team, required components are immediately dispatched via expedited air or sea freight. We also consult with clients to recommend a tailored inventory of standard consumables based on their specific operating environment to keep on-site.
Q6: Are there customization options available for the mast height to accommodate specific facility constraints?
A: Absolutely. While our standard free lifting heights range from 100mm to 210mm, our manufacturing facility can engineer customized mast configurations. This ensures the equipment perfectly matches your facility's specific door heights, racking systems, and container loading requirements without compromising structural integrity.
