As a premier manufacturer and supplier of heavy-duty earth-moving machinery, we present our latest compact skid steer loader engineered for high-intensity commercial applications.
Direct factory sourcing ensures rapid 3 to 7 days delivery to keep your projects on schedule.
Fully CE and EPA certified, guaranteeing strict compliance with global environmental and safety standards.
Designed with a versatile quick-hitch system for seamless integration with dozens of specialized attachments.
Built with premium components to deliver unyielding power, exceptional maneuverability, and long-term reliability for municipal, agricultural, and construction demands.
Step into a new era of earth-moving efficiency with our state-of-the-art mini crawler loader. When you grip the ergonomic controls, you immediately feel the responsive power surging from the premium engine, translating into smooth, precise movements across the job site. The deep, steady hum of the dual-pump hydraulic system assures you that this machine is built to handle relentless commercial demands without faltering. Its robust steel chassis gleams with an industrial-grade protective finish, meticulously engineered to withstand the abrasive grit of active construction zones and the corrosive dampness of agricultural fields.
Beyond its rugged exterior, this compact wheel and crawler loader is a masterclass in spatial problem-solving. It effortlessly glides through narrow alleyways, tight indoor corridors, and congested landscapes where traditional heavy machinery simply cannot operate. The tactile feedback from the high-traction tracks gripping muddy or uneven terrain provides operators with absolute confidence and stability. By integrating this dynamic loader into your operational fleet, you are not just acquiring a piece of equipment; you are securing a versatile workhorse that slashes manual labor hours, accelerates project timelines, and ultimately transforms complex site challenges into streamlined, highly profitable operations.
We empower commercial purchasers and regional distributors to build their own brand identity. Our dedicated production lines support extensive customization. You can dictate the exterior color palette to match your corporate fleet, modify specific configurations to suit local market demands, and prominently display your custom logo on the machinery. We provide a seamless, end-to-end OEM manufacturing service designed to elevate your market presence.
| Model | 360 | 460 |
| Engine | Koop/Briggs & Stratton | Koop/Honda/Loncin/Rato/Briggs & Stratton |
| Rated power | 13.5Kw | 15-18kw |
| Calibration speed | 3000rpm | 3600rpm |
| Cylinder | Single | Double |
| Displacement | 420cc | 639cc |
| Emission Standard | Euro 5/EPA | Euro 5/EPA |
| Rated load | 200kg | 300kg |
| Bucket volume | 0.12m³ | 0.12m³ |
| Walking speed | 0-6km/h | 0-6km/h |
Uncompromising Power Delivery: Equipped with top-tier engines from globally recognized brands, this loader guarantees consistent torque and horsepower, ensuring your team can push through dense soil, gravel, and debris without engine stall or fatigue.
Thermal Regulation Technology: An integrated, high-capacity oil cooler actively dissipates heat from the hydraulic fluid. This critical feature prevents system overheating, allowing the machinery to run stably during continuous, all-day operations under the scorching sun.
Precision Dual-Pump Hydraulics: The advanced dual-pump architecture divides hydraulic flow intelligently between the drivetrain and the lifting arms. This results in buttery-smooth simultaneous operations—you can drive, lift, and tilt the bucket concurrently without experiencing jerky movements or power drops.
Structural Integrity: Fabricated with reinforced, high-tensile steel at critical stress points, the lifting arms and chassis resist bending and torsion. This structural rigidity ensures maximum lifting force is transferred directly to the payload.
| Rated Load Capacity | 238 kg | Working Weight | 755-780kg |
| Bucket Volume | 0.13 m3 | Brang | Briggs & Stratton/RATO/KOOP |
| Maximum Lifting Force | 600 kg | Tyрe | Petrol / diesel |
| Speed of Work | 0-4.2 km/h | Output Power | 13.5HP/15HP/11.7HP |
| Preset Pressure | 18.5 Mpa | Fuel Consumption | ≤3.8, ≤4.2, ≤2.3 |
| Lifting time | 47 s | Start Mode | Electric Start |
| Fall Time | 32s | Fuel Tank | 6.6L, 6.7L, 5.5L |
| Tipping Time | 4.6s | Engine oil | 1.1L, 1.1L, 1.6L |
| Gradeability | 30% | Hydraulic Tank | 23L |
| Model | 800 | Foot pedal clearance | 270mm |
| Machine weight without attachment | 1069kg | Height to bucket hinge pin | 2160mm |
| Bucket weight | 80kg | Height of machine | 1400mm |
| Tipping load | 416kg | Without bucket length | 2160mm |
| Track width | 200mm | Overall length with bucket | 2830mm |
| Ground pressure | 0.261 | Overall operating height | 2800mm |
| Max Speed | 5.6km/h | Rollback o bucket on ground | 39° |
| Angle of departure | 28° | Rollback of bucket at full height | 69° |
| Minimum height of bucket pin from ground | 163mm | Tread width | 1150mm |
| Dumping angle at maximum height | 30° | Front turning radius without bucket | 1495mm |
| Dumping height | 1685mm | Width | 1006mm |
| Dumping reach | 610mm | Track gauge | 830mm |
| Ground clearance | 258mm | Bucket width | 1235mm |
| Model | 55 | Engine power | 36.8kw |
| Rated load | 890Kg | Maximum operating height | 3790mm |
| Overturning load | ≥1780Kg | Bucket pin height | 3020mm |
| Operation quality | 2880±3％Kg | Wheelbase | 1079mm |
| Largest traction | ≥25KN | Bucket capacity | 0.4m³ |
| Maximum digging force | ≥25KN | Diesel tank capacity | 80L |
| Maximum lifting force | 1780Kg | Speed | 12Km/h |
Decades of Manufacturing Excellence: Operating out of a state-of-the-art production facility, we utilize precision laser cutting and robotic welding to ensure every chassis meets exacting tolerances. Quality is engineered into the metal, not just inspected at the end.
Rapid Global Logistics: We maintain a highly optimized inventory system, enabling us to dispatch standard equipment orders within an astonishing 3 to 7 days. Our professional packaging ensures the machinery arrives at your port in pristine condition, ready for immediate deployment.
Unwavering Technical Partnership: We do not just sell machinery; we build long-term operational partnerships. Our dedicated engineering team is available for remote video diagnostics, guiding your on-site mechanics through any troubleshooting process step-by-step.
Proven Market Validation: Our equipment is currently driving productivity in over 80 countries. From sprawling Australian farms to demanding European construction sites, our loaders have earned a reputation for relentless durability and outstanding performance.
Navigating international equipment regulations can be complex, but our machinery eliminates this barrier. Every loader in this series has successfully passed rigorous testing to achieve CE certification. Furthermore, the core powerplants strictly adhere to Euro 5 and EPA emission standards. This ensures that the equipment can seamlessly clear customs and be legally deployed across European and North American markets, fully satisfying local environmental protection mandates.
Q: What is the standard warranty period for this earth-moving machinery?
A: We provide a comprehensive one-year (or 2000 operational hours) warranty. During this period, if any core components or parts are damaged due to non-human factors, we will supply brand-new replacement parts entirely free of charge.
Q: Can we customize the loader with our own corporate branding and specific colors?
A: Absolutely. We offer extensive OEM customization services. You can select custom paint colors, alter specific configurations based on your local environment, and have your proprietary company trademark or logo applied to the machinery before it leaves our factory.
Q: What are the accepted payment terms for international orders?
A: Our standard financial terms require a 30% T/T (Telegraphic Transfer) payment in advance to initiate production or secure inventory, with the remaining 70% T/T balance paid prior to the final shipping and dispatch of the goods.
Q: How quickly can you dispatch the equipment after an order is confirmed?
A: Thanks to our streamlined manufacturing and inventory management, standard models can be processed, packaged, and delivered to the port within an exceptionally fast timeframe of 3 to 7 days.
Q: How do you handle technical support if a component malfunctions on a remote job site?
A: We offer rapid-response remote diagnostics. You can record a video of the issue and send it to our technical support team. Our engineers will analyze the visual and audio feedback to pinpoint the exact cause and provide a step-by-step resolution. If a part is broken, we will expedite the replacement via air or sea freight.
Q: Are the attachments universally compatible, or do I need proprietary tools?
A: Our loaders utilize an industry-standard quick-hitch mounting plate. This allows you to effortlessly connect a vast array of conventional accessories and attachments, whether purchased from us or sourced locally in your country.
